• Insulation is optional (unrated)
• 26 gauge steel corrugated curtain
• Galvanized, primed and painted w/ 40 year paint warranty
• 18 gauge steel guides with 2" depth
• Sealed and lubricated steel bearings
• EZ-Tension Device for safe ratcheting of spring tension.
• See Video at "Support" tab above: Installation Manuals
• Note: Doors must be face mounted to wall of building and have adequate side room and head room.
• OPTIONAL: Easy Roller electric opener
• Call for discount on orders of 10 doors or more!
• Shipping costs on all orders are estimates only and are subject to change. Firm shipping costs can be provided in advance upon request. Customer must unload from truck.
• Production orders cannot be cancelled after 2 business days.

• Insulation is optional (unrated)
• 26 gauge steel corrugated curtain
• Galvanized, primed and painted w/ 40 year paint warranty
• Sealed and lubricated steel bearings
• 16 gauge steel guides with 2.25" depth
• Please consider the model # 2500 or 3652 for doors over 10' wide that will be subject to strong windward storms.
• Electric openers are optional
• Chain hoist is standard on doors over 10' W or over 10' H
• Note: Doors must be face mounted to wall of building and have adequate side room and head room.
• Shipping costs on all orders are estimates only and are subject to change. Doors over 12' long require special equipment.  Firm shipping costs can be provided in advance upon request. Customer must unload the truck.
• Production orders cannot be cancelled after 2 business days.

Production Lead Times:   Temple, GA (Atlanta area) = 2 weeks,  Houston, TX = 2 week,  Butler, IN = 2 weeks,  Anaheim, CA = 3 weeks,  Orlando, FL = 3 weeks,  Phoenix, AZ = 2 weeks, Sumner, WA = 3 weeks

• Insulation is optional (unrated)
• 26 gauge steel corrugated curtain
• Galvanized, primed and painted w/ 40 year paint warranty
• Doors over 6' wide include wind locks, which are clips attached along the edges of the door.  In the event of high winds, the wind locks will catch on to the vertical guides and prevent the wind from blowing the door in.
• Certified wind ratings do not apply for doors mounting to wood.
• 16 gauge steel wind lock guides with 2" depth
• Sealed and lubricated steel bearings
• EZ-Tension Device for safe ratcheting of spring tension.
• NO Chain Hoist option
• OPTIONAL: Electric opener
• Note: Doors must be face mounted to wall of building and have adequate side room and head room.
• Shipping costs on all orders are estimates only and are subject to change. Firm shipping costs can be provided in advance upon request. Customer must unload the truck.
• Production orders cannot be cancelled after 2 business days.

Production Lead Times:    Temple, GA (Atlanta area) = 2 weeks,  Houston, TX = 2 week,  Butler, IN = 2 weeks,  Anaheim, CA = 3 weeks,  Orlando, FL = 3 weeks,  Phoenix, AZ = 2 weeks, Sumner, WA = 3 weeks

• Sectional Overhead Door - Non-insulated

•  24 gauge steel sections with smooth finish
•  2" thick sections with 2 deep ribs and 6 shallow ribs.
•  Galvanized end caps have a 1-1/2" reveal on each end of door sections. Perimeter seal will cover this.
•  Please note: Center stiles are attached to the face of the door sections with Tog-L-Locs which may appear as somewhat discolored dimples.
• Optional windows or full-vision glass section
• Special order doors up to 30' wide or 24' high
• 10 year limited warranty on paint

•  1 year warranty on hardware

• 2 week min. production + 2-3 week transit time estimate
• Production orders cannot be cancelled after 2 business days.

• Sectional Overhead Door

• Non-insulated

• Heavy Duty 20 gauge steel sections with smooth finish
• 2" thick sections with 2 deep ribs and 6 shallow ribs
• Galvanized end caps have a 1-1/2" reveal on each end of door sections. Perimeter seal will cover this.
• Please note: Center stiles are attached to the face of the door sections with Tog-L-Locs which may appear as somewhat discolored dimples.
• Optional windows or full-vision glass section
• 10 year limited warranty on paint
• 1 year warranty on hardware

• 2 week min. production + 2-3 week transit time estimate
• Production orders cannot be cancelled after 2 business days.

• Sectional Overhead Door

• Insulated:  Polystyrene with vinyl backer
• 6.64 R-value (thermal protection)
• 24 gauge steel sections with smooth finish
• 2" thick sections with 2 deep ribs and 6 shallow ribs
• Galvanized end caps have a 1-1/2" reveal on each end of door sections. Perimeter seal will cover this.
• Please note: Center stiles are attached to the face of the door sections with Tog-L-Locs which may appear as somewhat discolored dimples.
• Optional windows or full-vision glass section

• Optional motor operator or chain hoist
• Special order doors up to 30' wide or 24' high
• 10 year limited warranty on paint
• 1 year warranty on hardware
• 2 wk. min. production + 2-3 wk. transit estimate
• Production orders cannot be cancelled after 2 business days.

• Sectional Overhead Door

• 3-layer insulated door = steel + insulation + steel

• 1-3/8" polystyrene insulation core bonded to steel
• 6.48 R-value (thermal protection)
• 27 gauge interior and exterior steel
• Sections are flush with wood-grain texture
• Galvanized end caps have a 1-1/2" reveal on each end of door sections. Perimeter seal will cover this.
• Optional windows
• 10 year limited warranty on paint
• 1 year warranty on hardware

• 2 wk. min. production + 2-3 week transit time estimate
• Production orders cannot be cancelled after 2 business days.

• Sectional Overhead Door

• Heavy Duty 20 gauge steel sections with smooth finish

• Insulated:  Polystyrene with vinyl backer
• 6.64 R-value (thermal protection)
• 2" thick sections with 2 deep ribs and 6 shallow ribs
• White color only.
• Galvanized end caps have a 1-1/2" reveal on each end of door sections. Perimeter seal will cover this.
• Please note:  Center stiles are attached to the face of the door sections with Tog-L-Locs which may appear as somewhat discolored dimples.
• Optional windows or full-vision glass section
• 10 year limited warranty on paint
• 1 year warranty on hardware

• 2 week min. production + 2-3 week transit time estimate
• Production orders cannot be cancelled after 2 business days.

• Sectional Overhead Door

• 3-layer insulated door = steel + insulation + steel
• 9.05 R-value (thermal protection)
• 2" polystyrene insulation core, bonded to steel
• 24 gauge exterior and 27 gauge interior steel
• Sections have shallow grooves on 4" or 5" centers and stucco finish
• Galvanized end caps have a 1-1/2" reveal on each end of door sections. Perimeter seal will cover this.
• Optional windows
• 10 year limited warranty on paint
• 1 year warranty on hardware

• 2 week min. production + 2-3 week transit time estimate
• Production orders cannot be cancelled after 2 business days.

• Sectional Overhead Door

• Heavy Duty 20 gauge steel exterior with smooth finish

• 25 gauge steel interior back panel
• Insulated with laid-in polystyrene sheeting
• 6.64 R-value (thermal protection)
• 2" thick sections with 2 deep ribs and 6 shallow ribs
• Galvanized end caps have a 1-1/2" reveal on each end of door sections. Perimeter seal will cover this.
• Please note: Center stiles are attached to the face of the door sections with Tog-L-Locs which may appear as somewhat discolored dimples.
• Optional windows or full-vision glass section
• 10 year limited warranty on paint
• 1 year warranty on hardware

• 2 week min. production + 2-3 week transit time estimate
• Production orders cannot be cancelled after 2 business days.

• Sectional Overhead Door

• Premium Thermal Protection R-Value = 19.40

• 2" thick polyurethane foam injected insulation core
• 2 layers of 27 gauge steel skins with stucco finish
• Sections have shallow grooves on 4" or 5" centers
• Galvanized end caps have a 1-1/2" reveal on each end of door sections. Perimeter seal will cover this.
• Optional windows or full-vision glass section

• Up to 32 ft. widths available upon request.
• 10 year limited warranty on paint
• 1 year warranty on hardware
• 2 wk. min. production + 2-3 wk. transit estimate
• Production orders cannot be cancelled after 2 business days.
